Long-Term Milacath™ (Large Animal) Single Lumen CVC Kit, Guidewire Introduction - 16Ga (5Fr) X 20cm (8in) With Separate Extension Line
Mila |
LA1620-2P-IND

Long-Term Milacath™ (Large Animal) Single Lumen CVC Kit, Guidewire Introduction - 16Ga (5Fr) X 20cm (8in) With Separate Extension Line

Special Order Item

This item is subject to our special order policy Special order items are ineligible for returns. These items will be shipped separately to the rest of your order. Lead times will be advised by our customer service team. .

Enquire today to create an account

Register
Description

The MILACATH® Single Lumen Large Animal Central Venous Catheter is designed for long-term venous access for administration of medications and fluids, blood sampling, total parenteral nutrition (TPN), and central venous pressure monitoring. Constructed from a biocompatible, non-kinking, non-thrombogenic polyurethane catheter material, MILACATH® catheters are designed for indwelling periods of up to 30 days. Multiple configurations are available including antimicrobial and non-antimicrobial catheters, integrated or separate extension sets, and guidewire or peel-away introducer placement techniques to accommodate a wide variety of large animal and specialty applications.


  • Designed for long-term venous access with recommended indwell times up to 30 days
  • Suitable for administration of medications and fluids, blood sampling, TPN, and central venous pressure monitoring
  • Biocompatible catheter material is non-kinking and non-thrombogenic
  • Single lumen design with distal tip exit port
  • 14Ga catheters feature both a distal tip exit port and an additional side exit port
  • Available with integrated or separate extension sets
  • Select configurations include antimicrobial catheter technology
  • Available in guidewire-placement and peel-away introducer-placement kits
  • Suture wings and catheter clamps facilitate secure fixation
  • Needle-free stasis valve and cap included on most configurations
  • Sterile, single-use only

Guidewire Kit Contents

(Applies to LA1615, LA1620, LA1415, LA1420, LA1220, LA1611-A, LA1615-A, LA1620-A, LA1420-A, LA1615-2P, LA1620-2P, LA1415-2P, and LA1420-2P)

  • Single Lumen Catheter
  • Extension Line with Clamp (integrated or separate depending on configuration)
  • Suture Wing(s)
  • Suture Clamp(s)
  • Guidewire Inside Coiled Housing
  • Dilator(s)
  • Catheter-over-Needle Introducer(s)
  • Size 15 Scalpel
  • 2-0 Polypropylene Suture with Curved Needle
  • 2-0 Polypropylene Suture with Straight Needle
  • Needle-Free Stasis Valve
  • Stemless Cap
  • Gauze (4)
  • Note:
  • LA1615-2P, LA1620-2P, LA1415-2P, and LA1420-2P include a tethered cap (#8090) in place of the stasis valve and stemless cap.

Peel-Away Introducer Kit Contents

(Applies to LA1615-PI and LA1420-PI)

  • Peel-Away Introducer
  • Single Lumen Catheter with Integrated Extension and Clamp
  • Suture Wing(s)
  • Suture Clamp(s)
  • Size 15 Scalpel
  • 2-0 Polypropylene Suture with Curved Needle
  • 2-0 Polypropylene Suture with Straight Needle
  • Needle-Free Stasis Valve
  • Stemless Cap
  • Gauze (4)

Bovine Kit Contents

(Applies to B1220)

  • Single Lumen Catheter
  • Introducer
  • Guidewire
  • Dilator
  • Suture Wings with Clamps
  • Needle-Free Stasis Valve
  • Cap

Single Lumen MILACATH® Large Animal Central Venous Catheter Kit Comparison Guide

Item # Configuration Catheter Size Length Extension Set Antimicrobial Typical Use
LA1615 Guidewire Kit 16Ga / 5Fr 15cm Integrated No Foals
LA1620 Guidewire Kit 16Ga / 5Fr 20cm Integrated No Foals
LA1415 Guidewire Kit 14Ga / 6Fr 15cm Integrated No Large Animal
LA1420 Guidewire Kit 14Ga / 6Fr 20cm Integrated No Large Animal
LA1220 Guidewire Kit 12Ga / 8Fr 20cm Integrated No Large Animal
LA1611-A Antimicrobial Guidewire Kit 16Ga / 5Fr 11cm Integrated Yes Foals
LA1615-A Antimicrobial Guidewire Kit 16Ga / 5Fr 15cm Integrated Yes Foals
LA1620-A Antimicrobial Guidewire Kit 16Ga / 5Fr 20cm Integrated Yes Foals
LA1420-A Antimicrobial Guidewire Kit 14Ga / 6Fr 20cm Integrated Yes Large Animal
LA1615-2P Guidewire Kit with Separate Extension 16Ga / 5Fr 15cm Separate No Foals
LA1620-2P Guidewire Kit with Separate Extension 16Ga / 5Fr 20cm Separate No Foals
LA1415-2P Guidewire Kit with Separate Extension 14Ga / 6Fr 15cm Separate No Large Animal
LA1420-2P Guidewire Kit with Separate Extension 14Ga / 6Fr 20cm Separate No Large Animal
LA1615-PI Peel-Away Introducer Kit 16Ga / 5Fr 15cm Integrated No Foals
LA1420-PI Peel-Away Introducer Kit 14Ga / 6Fr 20cm Integrated No Large Animal
B1220 Bovine Guidewire Kit 12Ga / 8Fr 20cm N/A No Bovines
